Category
Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)
Mfr
ebm-papst Inc.
Series
600F
Packaging
Box
Part Status
Active
Voltage – Rated
12VDC
Size / Dimension
Square – 60mm L x 60mm H
Width
15.00mm
Air Flow
17.1 CFM (0.479m³/min)
Static Pressure
–
Bearing Type
Sintec
Fan Type
Tubeaxial
Features
–
Noise
27.0dB(A)
Power (Watts)
1 W
RPM
3900 RPM
Termination
2 Wire Leads
Ingress Protection
–
Operating Temperature
-4 ~ 158°F (-20 ~ 70°C)
Approval Agency
CE, CSA, UL, VDE
Weight
0.066 lb (29.94 g)
Current Rating (Amps)
–
Voltage Range
10.8 ~ 13.2VDC
Material – Frame
Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material – Blade
Polyamide (PA), Nylon, Fiberglass Reinforced
Lifetime @ Temp.
50000 Hrs @ 20°C
